Breezeway® II Delivery Sheath

Breezeway® II Delivery Sheath

Fixed Curve Guiding Sheath

The Breezeway® II Delivery Sheath is intended for the introduction of diagnostic and therapeutic devices into the human vasculature, including intracardiac and other placements.

  • Soft atraumatic tip
  • Smooth tapered sheath tip dilator transition during peripheral and transseptal access
  • Superior curve retention for catheter placement
  • The dilator is constructed of a low friction radiopaque material
  • Accepts maximum guidewire up to 0.038”/0.97 mm
  • Sideport holes on distal end for aspirating and flushing the guiding sheath
  • Hydrophobic coated sheath
  • Low friction nylon inner liner
  • Clear view of the distal marker band under fluoroscopy for easy positioning
  • Flexsteer™ reinforced braid technology provides exceptional control, kink resistance, while maintaining flexibility
  • SureSeal™ hemostatic valve technology to minimize air embolism and blood loss

Diameter Options

Diameter Options

Curve Configurations

Curve Configurations

Product Diagram

Product Diagram

Kit includes:

  • (1) Breezeway II Sheath
  • (1) Breezeway II Dilator
Model #
Kit (One per box)
A1
Sheath Inner Diameter
A2
Usable Sheath Length
A3
Sheath Tip Curve
B1
Usable Loader Length
BG060079045 6 F 79 cm 45° 8.5 cm
BG060110045 6 F 110 cm 45° 8.5 cm
BG070079045 7 F 79 cm 45° 8.5 cm
BG070079180 7 F 79 cm 180° 8.5 cm
BG070110045 7 F 110 cm 45° 8.5 cm
BG080110045 8 F 110 cm 45° 12.5 cm
BG080079045 8 F 79 cm 45° 12.5 cm
BG080079180 8 F 79 cm 180° 12.5 cm
BG090110045 9 F 110 cm 45° 12.5 cm
BG090079045 9 F 79 cm 45° 12.5 cm
BG090079180 9 F 79 cm 180° 12.5 cm
BG100079045 10 F 79 cm 45° 12.5 cm
BG100079180 10 F 79 cm 180° 12.5 cm
BG100110045 10 F 110 cm 45° 12.5 cm
BG110079045 11 F 79 cm 45° 16.5 cm
BG110079180 11 F 79 cm 180° 16.5 cm
BG120079045 12 F 79 cm 45° 16.5 cm
BG140079045 14 F 79 cm 45° 16.5 cm

Plus Kit includes:

  • (1) Breezeway II Sheath
  • (1) Breezeway II Dilator
  • (1) Loader
Model #
Kit (One per box)
A1
Sheath Inner Diameter
A2
Usable Sheath Length
A3
Sheath Tip Curve
B1
Usable Loader Length
BG060079045L 6 F 79 cm 45° 8.5 cm
BG060110045L 6 F 110 cm 45° 8.5 cm
BG070079045L 7 F 79 cm 45° 8.5 cm
BG070079180L 7 F 79 cm 180° 8.5 cm
BG070110045L 7 F 110 cm 45° 8.5 cm
BG080110045L 8 F 110 cm 45° 12.5 cm
BG080079045L 8 F 79 cm 45° 12.5 cm
BG080079180L 8 F 79 cm 180° 12.5 cm
BG090110045L 9 F 110 cm 45° 12.5 cm
BG090079045L 9 F 79 cm 45° 12.5 cm
BG090079180L 9 F 79 cm 180° 12.5 cm
BG100079045L 10 F 79 cm 45° 12.5 cm
BG100079180L 10 F 79 cm 180° 12.5 cm
BG100110045L 10 F 110 cm 45° 12.5 cm
BG110079045L 11 F 79 cm 45° 16.5 cm
BG110079180L 11 F 79 cm 180° 16.5 cm
BG120079045L 12 F 79 cm 45° 16.5 cm
BG140079045L 14 F 79 cm 45° 16.5 cm
